16 SEER: 4.25 Ton Quad-Zone Ductless Mini Split AC - Heat Pump:  With a 51000 BTU total Cooling / HEATING Capacity, this Quad Zone INVERTER mini split air conditioner can cool 4 separate zones (9000 + 12000 + 12000 + 18000 BTU) for a total coverage area of 2200 ft² (350 ft² + 550 + 550 ft² + 800 ft² areas). 16 SEER cooupled with Advanced Inverter technology provides the benefits of low operation temps, rapid cooling / heating as well as maximum energy efficiency.

Home > Mini Split > Quad-Zone >

4 Ton Quad Zone Mini Split



Air Conditioners - Split AC's, Portable AC's, Air Cooler Source
855-382-8110
Mini Split Air Conditioners
Search BY BTU Capacity:


Inverter Systems
Single-Zone
Dual-Zone
Tri-Zone
Quad-Zone
Quint-Zone (5)
Energy Star
Temperature Control: Portable A/C's, Window A/C's, Air Coolers, Ductless Splits,
Portable AC's >
Mini Wall Splits >
Ceiling Cassettes >
Suspended Ceiling >
Central AC's >
Window AC's >
Air Coolers >
Space Heaters >
Air Purification: IONIZERS, HEPA Filters, UV-TION
Ionizers >
HEPA >
UV/Tion >
Supplies >
Humidity Control: Humidifiers, Dehumidifiers
Humidifiers >
Dehumidifiers >

Accessories
48000 BTU quad Zone Mini Split
Mini Split AC Heat Pump Inverter System

Indoor Units Remote Control Outdoor Unit Installation Kit

Technical Data:
  • 51000 BTU Cooling Capacity: (9k + 12k + 12k + 18k)
  • 51000 BTU Heat Pump Capacity: (9k +12k + 12k + 18k)
  • INVERTER DC TECHNOLOGY: 16 SEER
  • Quad-Zone Setup (4 Air Handlers)
  • 1 Year Warranty on all Parts View Details >
  • 5 Year Warranty on Compressor View Details >

4 Ton Quad-Zone Mini Split: 9k+12k+12k+18k

Price: $3499.45 Free Shipping

*When all four air handlers are running simultaneously at full capacity,
the total combined BTU output is limited to that of the outdoor condenser.

Mini Split AC FeaturesTop

mini split features Top Line Features:
  • Quad Air Handlers for Multi-Zone Placement.
  • INVERTER DC TECHNOLOGY: 16 SEER.
  • Intelligent Mechanical Defrosting.
  • Washable Filters - Biologically Activated Enzyme.
  • Low Startup Temps - MAXIMUM EFFICIENCY.
  • Pre-charged w/ R-410A Freon For 25' [x4] of Piping.
  • Sleep Mode - 24 hour ON/OFF Timer - Memories.
  • Enhanced Copper Coil - Wide Angle Air Spread.
  • Over Current and Thermal Protection.
  • Flexible, Quick Installation - Easy Operation.

Quad Zone Mini Split Features


Mini Split AC SpecsTop

9000 BTU Indoor Air Handler Specs: CLICK TO ENLARGE
WMMS-12EW-V2B

12000 BTU Indoor Air Handler Specs: CLICK TO ENLARGE

WMMS-12EW-V2B

18000 BTU Indoor Air Handler Specs: CLICK TO ENLARGE
WMMS-12EW-V2B
spacer Outdoor Compressor Unit Specs: CLICK TO ENLARGE
WMMS-45CH-V2B




MITSUBISHI Compressor 16 SEER
ETL LISTED R410A refrigerant Cooling & Heating


Mini Split Installation KitTop
Install Kit Contents:
  • 25 Feet Flared Insulated Copper Tubing x 4
  • 25 Feet Pipe Insulation x 4
  • Drain Pipe (outdoor)
  • Defrost Wire
  • Wire Harness Between Indoor & Outdoor x 4
  • Remote Control w/ Wall Brackets & Batteries x 4
  • Wire Harness Outside Unit to Circuit Breaker
Includes Install Kit Install Kit
***Extend one or more of the four (4) included 25 foot line sets to a total length of 50 feet. Just $99 per 25' extension.***


Inverter TechnologyTop
DC Inverter Mini Split AC Heat Pump WHAT IS DC INVERTER?

DC Inverter Air Conditioners are the ultimate cooling technology of the HVAC field. They are called "DC inverter" because the alternative current (AC) is converted to Direct Current (DC) then, direct current inverted back to Alternative current with desired frequency. The current supplied through the wall outlet has fixed frequency which is 60 Hertz. Different frequencies supplied to the compressor will result in different running speeds of the compressor. Inverter control systems use Pulse Amplitude Modulation (PAM) that is the most advanced and energy efficient method of inverting the current. DC Inverter AC's bear special compressors that their speed could be changed by increasing or decreasing the frequency of the supplied power. Therefore, unlike conventional split Air Conditioners Pumps which cycle between on and off repeatedly, the DC Inverter control system will monitor the room temperature and adjust the compressor speed automatically.

Conventional compressors turn on and off to maintain the room temperature at desired level. This will result compressor to draw tremendous energy each time it starts up. This will also reduce the life-span of the compressor and other components that are turning on and off. Once a conventional system is running, it runs at its maximum speed, consuming the maximum amount of energy in order to produce the maximum of cooling to maintain the desired temperature. The system will then cycle between on and off in an effort to maintain this temperature. When a DC Inverter compressor initially starts up, it runs with a higher speed to bring the room temperature to desired level rapidly, Once the set temperature is reached, it slows down and adjust its capacity just to counter the heat loss or heat gain of the building. Constant temperature is maintained.


DC Inverter Energy Efficient Heating & Cooling Mini Splits


Inverter Mini Split Air Conditioner Saves Money


Inverter Mini Split Air Conditioners Are Energy Efficient & Save Money


Ductless Split InstallationTop
BASIC OVERVIEW: The indoor unit is hung like a picture frame approximately 6 - 8 feet above the floor usually on an exterior wall. A 2-3 inch hole must be made behind the indoor unit in the exterior wall to run the refrigerant copper tubing, electrical wires and the condensate drain to the outside unit. The indoor unit and outdoor unit are connected to each other by means of refrigerant copper tubing and electrical cables. The condensing unit comes pre-charged with R410A Freon however, procedures such as conducting leak tests etc. are still important steps in ensuring proper functioning of a split AC. *Although installation may seem easy to some, certain tools and experience is necessary to complete setup of a mini split* Click for Installation Tip. It is highly advised a certified HVAC technician complete installation to be eligible for warranty. See warranty details below > Ductless Split Air Conditioner Installer

Installation Diagram For Mini Split Air Conditioning Units

Multi Zone Mini Split Air Conditioners / Heat Pumps Provide Flexible Layout Options


WarrantyTop
*5 Year Compressor - 2 Year on all other Parts* Registration card will be sent with unit, this card should be completed by an HVAC technician (installer). Installation of a mini split must be completed by a licensed HVAC (Heating, ventilating, & air conditioning) company to ensure any issues encountered in the future are not due to improper installation / workmanship. Even though mini split setup is below the expertise requirements of central AC systems, these are not "plug-n-play" units that can be properly installed without certain tools any prior HVAC - electrical knowledge. The installation includes electrical, gas, and refrigerant connections and generally regulated by a multiple sets of laws, codes and guidelines, at the federal, state and local levels. The failure to properly install HVAC equipment can raise personal safety and performance concerns. Warranty service - troubleshooting is provided through the contractor / installer and will be upheld as long as policies are observed. Once a non-defective unit is installed by a HVAC company, chances of anything going wrong are very slim and almost all contractors will guarantee there workmanship and provide future service free of charge (installation warranty). If it was determined that the unit is not functioning due to a defect and needs to be replaced, the part will be sent free of charge up to 2 year from date of purchase or 5 years for compressor. If you receive a damaged or defective product, a replacement unit will be sent out Free of cost. Damaged / Defective product will be picked up and brand new exchange will be shipped out. Download Manual - Warranty Polices >


Mini Split ShippingTop
These multi-zone mini split units ship out of Missouri via YRC Freight or via a similar freight service, and under normal conditions, are loaded and in transit within 2 business days from payment receipt. Depending on where you are geographically located, transit time from this point varies, but typically amounts to 2-5 business days. Please provide a contact phone # upon checkout where recipient of order can be reached. SOMEBODY MUST BE ON SITE TO ACCEPT / SIGN FOR Order. This unit can only be shipped to addresses within the Contiguous USA (lower 48 states). Quad Zone Mini Split Air Conditioners Shipped To Your Home Or Business via YRC Freight
Dotted Line
Options
Swap 1 - 9k Wall Mount for Cassette:  (+) $130 *
Swap 1 - 12k Wall Mount for Cassett:  (+) $100
Swap 1 - 18k Wall Mount for Cassette:  (+) $125
Swap all 4 Wall Mounts for Cassettes:  (+) $445
* No 9000 BTU cassettes - need to exchange for 12000 BTU
Swap 1 - 9k Mount for Susp. Ceiling:  (+) $190
Swap 1 - 12k Mount for Susp. Ceiling:  (+) $232
Swap 1 - 18k Mount for Susp. Ceiling:  (+) $248
Swap all Mounts for Susp. Ceiling:  (+) $902
This unit
*If alternate air handler types are preferred, request invoice with preferred options upon checkout or contact us.
